Wireless light controller for led street light control system

FOB Reference Price:Get Latest Price
US $25-45 / Pieces | 10 Piece/Pieces Wireless light controller for led street light control system (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shanghai, China (Mainland)
Brand Name:
Shuncom (OEM is acceptable)
Model Number:
SZ10-R1A-M
Type:
Remote Control
Max. Load Power:
400W
Voltage:
220V
Name:
Wireless light controller for led street light control system
Application:
Control Lights
Certificates:
CE ROHS EMC
Warranty:
5 Years
Output power:
85V:<265W
Working temperature:
-40℃~ +85℃
Output rated current:
2A
Radio frequency:
2.4G
Dimming Control Type:
0-10V/PWM
Color:
White
Supply Ability
Supply Ability:
20000 Piece/Pieces per Month Wireless light controller for led street light control system
Packaging & Delivery
Packaging Details
Wireless light controller for led street light control system
each piece in one small bubble bag, 60 boxes in one master carton(48cm*32cm*31.5cm)
Port
Shanghai
Lead Time :
7-30 days (according to your quantity)
Specification
Setting Information
Dimensions
118.3×43×30(mm)
Transmission distance
400M
Product output
Single-phase AC
Data collection
U,I,P.Q.W.COSΦ
Antenna band
2.4G
Antenna gain
3DB
Antenna VSWR
《2.0
Antenna type
External
Product Description

Product Details

SZ10-R1A-M controller is compliant with IEEE802.15.4 protocol of ZIGBEE communication standard. It has the advantages of far communication distance, strong anti-interference capability and flexible networking, realizing peer-to-peer and peer-to-multi peer transparent data transmission among devices, and constructing star network or mesh network topology.

Product Details

SZ10-R1A-M single-lamp controller consists of current, voltage and electric energy metering circuit which collect real-time load performance and power consumption of single-lamp controller. It helps to largely reduce work load of street lamp management department, and improve working efficiency, therefore significantly improve energy-saving benefit of all society.

Installation Process
Applications
Certifications
Company Information
FAQ

Q1. Can I have a sample order for light Controller?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?

A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than

Q3. Do you have any MOQ limit for light Controller order?

A: Low MOQ, 10 pc for sample checking is available

Q4. Have you any modifications of NEMA controller, supporting DALI protocol?

A: Our Zigbee proprietary protocol and do not support DALI.

Q5. If the gateway is not working or lost, can the lighting controller switch automatically?

A:There are local strategies. Lighting controller can solve this problem.

Q6.How many lighting controllers can a gateway usually control?

A: A gateway can control 200 pcs lighting controller under normal circumstances.
